1) Application: for cable braiding, hose braiding, wire mesh woven etc. 2) Material: low carbon steel 3) Diameter: 0.15mm~2.00mm 5) Packing: 2kg~500kg, on spool or in coils 6) Advantages: Thick zinc coating, good corrosion resistance, firm zinc coating, etc. 7) All can be produced according to customers actual requirement.

Diameter: 1.80mm, 2.65mm, 3.25mm, 4.00mm Min. Tensile strength: 700Mpa or 1100Mpa or 1570Mpa or 1770Mpa, 1860Mpa Zinc Coating: according to BS443( BS EN 10244-2:2001) Material: high carbon steel Standard: IS: 2141 or BS:183 Packing: coils or reels

Cable Armour Wire, CAW Wire, Wire for cable armouring, Armouring Cable Wire 1) Application: Hot dipped galvanized steel wire for cable armouring 2) Diameter: 0.90, 1.25, 1.60, 2.00, 2.50, 3.15, 4.00mm 3) Technical Info: Surface: hot-dipped zinc coated Tensile strength:340-500 N/mm2 for all sizes Elongation: Min. 10% for all sizes 4) Packing: jumbo coil, Inner 4 metal strips and 4 D-ring with plastic bag and PE woven cloth outside. 5) Standard: according to BS EN10257-1, EN10244-2 (BS443, BS5467, BS1442) 6) All can be produced according to customers actual requirement.

1) Material: AISI304, AISI316 2) Construction: 1×7, 1×19, 1×37, 7×19, 6×19+FE, , 7×7, 6×7+FE, 7×37 etc. 3) Diameter 0.20mm 30.00mm 4) Packing: on reels 5) Standard: DIN3055, DIN3052, DIN3053, DIN3060, DIN3054, DIN3066 etc. All can be produced according to customers actual requirement. 6) Application: widely used in petroleum industry, chemical industry, textile industry, machinery, precision instrument, medical instrument, automobile, decoration, fishing and other general areas. Minimum Order Quantity: 1000meters

Application: for cable armoring. Finish: The surface of Galvanized steel tapes is free form scales, seams, Zinc flakes and other surface imperfection. The zinc coating smooth and continuous. Thickness: 0.15 mm to 2.00 mm Width: 4 mm to 1250 mm Technical Specifications: Tensile Strength: 28 to 50 kgf/mm2 Elongation: Minimum 10% on 250 mm gauge length. Zinc Coating: Minimum 110 g/m2 (total weight on all four sides). However, this can be increased to suit customer s requirements.

The copolymer coated (ECCS) steel tape is made from high quality cold rolled steel tape, and the copolymer film is made from EMMA material with excellent heat seal. The surface of tape is smooth , no wrinkle and pucker and oxidation spots, the winding is neat. The film is blue, green or nature color. It is applicable for manufacturing the copolymer coated steel tape used for shielding damp- proof and armor layer of communication of optical cable. Length: 1030-5000m or your request Width: 12-610mm Steel Coil Thickness: 0.13 0.15mm Copolymer Coat Thickness: 0.05mm Total Thickness: 0.21/ 0.25 / 0.26mm Tensile Strength: 310-390MP Peel Strength: Exceed 6.13N/cm Elongation: Exceed 15% Inner Diameter: Heat Seal Strength: 150/406/508mm Min 17.5N/cm

1) Introduction: Oil Tempered wire is a steel wire with superior elasticity and ductility obtained by oil-quenching and tempered process. OT wire has excellent resistance against heat, fatigue and deformation. OT wire s main applications are springs for repeated dynamic loads, including engine valve spring. 2) Material: High Carbon Steel, C:>0.5% 3) Diameter: 0.5-17.00mm 4) Standard: ASTM A229, EN10270-2, JIS G 3560-1994 5) Regular grade: 55SiCr, 54SiCr6, SAE9254, SAE9254V, 60Si2MnA, 50CrVA, 65Mn etc.

Specifications: 1) Grade: 201, 202, 301, 303, 304, 304L, 305, 316, 316L, 321, 410, 416, 420, 430 1.4301, 1.4306, 1.4845, 1.4401, 1.4371, 1.4597, 1.4541, etc. 2) Standard: ASTM, EN, DIN, JIS 3) Diameter: 0.05-20mm 4) Surface: bright, plain, black, dull and EPQ quality 5) Type: spring, welded, tig, mig etc soft and hard 6) Tensile strength: soft (650-850N/mm2) and hard (around 2000N/mm2) 7) Packing: in Coil or in Spool then in Carton or Straighten and cut to customized length. 8) Quality assurance: Mill Test Certificate is supplied with shipment, third Party Inspection is acceptable

Steel Wire Rope

Application: for general application spring and mechanical spring. Beside to make the wire according to the standard, we also try to supply the wire according customer s special requirement. Technical specification: (1)Standard: DIN17223-1-1984, EN10270-1, ASTM-A227, GB4357-89 (2)Size: 0.30mm-14.0mm
